SMARTMAC 200

Operating unit for on-site calibration and configuration of SMARTPAT sensors

  • 2-wire loop powered, 4…20 mA/HART® 7
  • Displays main parameter and temperature
  • With sensor exchange function, error and calibration logbooks
  • Also available as hygienic stainless steel and intrinsically safe versions

SMARTMAC 200 – Version with aluminium housing

Operating unit for process analytics SMARTMAC 200 – Version with aluminium housing

The SMARTMAC 200 is a loop powered operating unit for configuration and calibration of SMARTPAT PH, ORP and COND sensors, including error and calibration logbook. It comes as die-cast aluminium or hygienic stainless steel version.
